Condition:
New
Range of Spindle Speed(r.p.m):
1 - 24000 rpm
Positioning Accuracy (mm):
0.01 mm
No. of Spindles:
Single
Working Table Size(mm):
600×900
Machine Type:
CNC Router
Travel (X Axis)(mm):
600 mm
Travel (Y Axis)(mm):
900 mm
Repeatability (X/Y/Z) (mm):
0.01 mm
Spindle Motor Power(kW):
1.5
CNC or Not:
CNC
Place of Origin:
Shandong, China
Nom de marque:
REDSAIL
Voltage:
220V
Dimension(L*W*H):
1460x1150x1400 (mm)
Power (kW):
1.5
Weight (KG):
135
Control System Brand:
NC Studio, Mach3, DSP, RichAuto
Warranty:
One Year
Key Selling Points:
Low Noise Level
Applicable Industries:
Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Home Use, Printing Shops, Construction works , Advertising Company
Machinery Test Report:
Provided
Video outgoing-inspection:
Provided
Warranty of core components:
1 Year
Core Components:
Bearing, Motor, Gear
X,Y,Z Guide:
Ball screw and Linear square guide way
Gantry Height:
110mm
Drive type:
Micro-Step Stepper Motor
Spindle:
800W high speed (water cooling)
Max Moving Speed:
8000 mm/min
Max Machining Speed:
4000mm/min
Resolution:
0.02mm
Repeatability:
0.01mm
Command code:
HPGL, G-code
Power:
AC220V±10% / 50~60Hz
Showroom Location:
Canada
Marketing Type:
Ordinary Product
