Condition:
New
Range of Spindle Speed(r.p.m):
50 - 24000 rpm
Positioning Accuracy (mm):
0.02 mm
No. of Spindles:
Single
Working Table Size(mm):
720*1150*20mm
Machine Type:
CNC Router
Travel (X Axis)(mm):
600 mm
Travel (Y Axis)(mm):
900 mm
Repeatability (X/Y/Z) (mm):
0.02 mm
CNC or Not:
CNC
Place of Origin:
China
Nom de marque:
JFT
Voltage:
110V/220V
Weight (KG):
145
Control System Brand:
Mach3
Warranty:
1 Year
Key Selling Points:
Automatic
Applicable Industries:
Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Bevera
Machinery Test Report:
Provided
Video outgoing-inspection:
Provided
Warranty of core components:
1 Year
Core Components:
Bearing, Motor, Pump, Gear, PLC, Pressure vessel, Engine, Gearbox
Machine name:
Foam cutting machine
Working area:
900mm*600mm *120mm
Spindle power:
0.8kw/1.5kw/2.2kw
Type of Screw:
TBI SFU1605 ball Screw
Cooling mode:
Water cooling
Control system:
Mach3 ( Usb Port)
Stepper motor:
57Type 5.6A
Carving accuracy:
0.03mm
Drive:
Independent drives
Guide rail:
0ptical axis+support round rail
After-sales Service Provided:
Online support
Local Service Location:
None
After Warranty Service:
Video technical support, Online support
Showroom Location:
None
Marketing Type:
New Product 2020
Certification:
CE
